Lackender by ECS Swing Boom Cutter Skid Steer Attachment Dimensions

Swing Boom Cutter

The Lackender by ECS Swing Boom Cutter is designed for cutting banks, fence lines and right of ways along with cutting trails. With a reach of 96″ when extended horizontally and a vertical reach of 16′, this skid steer attachment easily tackles trimming tree limbs. The Swing Boom Cutter can also swing to the right to be used as a side cutter. Powered by a high torque motor with built-in relief valve and maximum supply pressure of 4,000 PSI, this cutter has a significant reach advantage over our typical cutter.

Specifications
  • Maximum Supply Pressure of 4,000 PSI
  • 3″x16″ Tilt Cylinders
  • ⅝” AR400 Blades
  • 44″ Cut
  • 3″ Cutting Capacity
  • Does Not Require Case Drain
  • Universal, 7 Pin, 8 Pin, and 14 Pin Wiring Harnesses Available
  • John Deere and Euro Mounts Available
  • Powder-coated Finish
  • Protective Sleeve on Hydraulic Hoses
Warranty

Lackender by ECS products are covered by a limited manufacturer’s warranty and are warranted to be free from defects in workmanship or materials for a period of 12 months from initial sale.

Weight N/A
